Home » Products » Bitumen Emulsion » Bitumen Emulsion

Bitumen Emulsion

Bitumen Emulsion
Bitumen Emulsion
Send Inquiry
Product Code : 06
Price And Quantity
  • Minimum Order Quantity
  • 100
  • Unit of Measure
  • Barrel/Barrels
Product Specifications
  • Type
  • Modified Bitumen
  • Grade
  • MS, RS, SS1, SS2 (Cold Mix)
  • Usage
  • Road
  • Color
  • Black
Product Description

The Bitumen Emulsion provided by us is an excellent stock of bitumen emulsion.  They are widely used in road construction work. They are dispersion of bitumen in an aqueous continuous phase, stabilized by the addition of an emulsifier. The Bitumen Emulsion can also be used in damp environment on wet aggregates and are available in an excellent packing at competitive price. Further, they are known for their features such as easy application on road repair work in minimum time, provides better tack coat and can be used in all weathers

Tack Coat Tack Coat application:

  • A light spray of Bitumen Emulsion, which may be hand or machine sprayed
  • Used to ensure a good bond between an old and a new bituminous surfacing layer
  • Applied very thin and must over the entire surface evenly

GRADES OF BITUMEN EMULSION

  • Rapid Set - RS-1 & RS-2
  • Medium Set - MS
  • Slow Set - SS-1 & SS-2
  • RS-1 : Tack-Coating
  • RS-2 : Surface Dressing,
  • MS : Premix carpet, Patch Repair
  • SS-1 : Priming
  • SS-2 : SDBC, BC, BM, Slurry Seal,PMB/Latex Emulsion : Micro-surfacing

Bitumen Emulsion R.S. - 1

Key Feature:

  • A viscous liquid emulsion with high binder content
  • Suitable for Track - Coating
  • Advantages:
  • Easy and uniform spray
  • Provides high adhesion
  • Enhances structural strength of layers
  • Prevents lateral movement of structural layers
  • Provides an impervious layer to prevent water ingress from water table below the road layers

Technical Specifications:

  • Key properties as per IS 8887: 2004

Product Applications

  • Application rate as per MORTH specifications

Bitumen Emulsion R.S. -1 is available in

  • Bulk
  • RC Drums 200 Kg
  • MS Drums 200 Kg

Physico-chemical Properties of Cationic Bitumen Emulsion as per IS:8887- 2004 And Our Report


Properties of Bitumen Emulsion

Requirement

Result.

Residue on 600 micron IS sieve(% mass)

0.05 max.

0.03

Viscosity by Saybolt Furol Viscometer, seconds At 500 C

20-100

55

Coagulation of emulsion at lowtemperature

Nil

Nil

Storage stability after 24 hrs. , %, max.

2.0

1.68

Particle charge

+ve

+ve

Coating ability and water resistance
(a) Coating, dry aggregates
(b) Coating after spraying water
(c) Coating, wet aggregates
(d) Coating after spraying water

-

-

Stability to mixing cement, % coagulation

Nil

Nil

Miscibility with water (coagulation)

No Coagulation

No Coagulation

Test on residue :
(a) Residue by evaporation, %
(b) Penetration, 250C/100 gm/5 sec.
(c) Ductility, 270C/cm.,
(d) Solubility In Trichloroethylene, %


60 min.
80-150
50 min.
98 min.


62
108
71
99


Bitumen Emulsion R.S. - 2

Key Feature:

  • A viscous liquid emulsion with high binder content
  • Suitable for surface dressing, grouting and penetration macadam applications

Advantages:

  • Easy and uniform spray
  • Provides high adhesion
  • Enhances structural strength of layers
  • Prevents lateral movement of structural layers
  • Provides an impervious layer to prevent water ingress from water table below the road layers

Technical Specifications:

  • Key properties as per IS 8887: 2004

Product Applications:

  • Application rate as per MORTH specifications

Emulsion R. S. - 2 is available in

  • Bulk
  • RC Drums 200 Kg
  • MS Drums 200 Kg

Physico-chemical Properties of Cationic Bitumen Emulsion as per IS:8887- 2004 And Our Report.


Properties of Bitumen Emulsion

Requirement

Result.

Residue on 600 micron IS sieve(% mass)

0.05 max.

0.03

Viscosity by Saybolt Furol Viscometer, seconds At 500 C

100-300

158

Coagulation of emulsion at low temperature

Nil

Nil

Storage stability after 24 hrs. , %, max.

1.0

.068

Particle charge

+ve

+ve

Coating ability and water resistance
(a) Coating, dry aggregates
(b) Coating after spraying water
(c) Coating, wet aggregates
(d) Coating after spraying water

-

-

Stability to mixing cement, %coagulation

Nil

Nil

Miscibility with water (coagulation)

No
Coagulation--

No
Coagulation--

Test on residue :
(a) Residue by evaporation, %
(b) Penetration, 250C/100 gm/5 sec.
(c) Ductility, 270C/cm.,
(d) Solubility In Trichloroethylene, %


67 min.
80-150
50 min.
98 min.


69
119
78
99


Bitumen Emulsion M.S.

Bitumen Emulsion M.S. is specially designed water based Bitumen Emulsion with moderate viscosity and setting time range in between fast setting and slow setting Bitumen Emulsion that makes it an ideal product for premixing applications and patch repairing . It is chocolate brown in colour and is a free flowing liquid at ambient temperature. Bitumen Emulsion MS is manufactured strictly as per IS 8887  2004.

Advantages:

  • No Heating Require
  • Cost Efficient
  • Easy and Uniform Mix
  • Low Temperature Curing
  • Minimum Preparation Time for Surface Repair
  • Medium Setting Time
  • High Adhesive Properties
  • Stable Patch
  • Resistant to Stripping by Water
  • Environment Friendly
  • Bonds well with Cool, Damp Surfaces

Application
Emulsion M.S. is ideally suited for:

  • Pot Hole Repair/Patch work
  • 20 mm Pre-Mix Carpet

Emulsion M.S. is available in

  • Bulk
  • RC Drums 200 Kg
  • MS Drums 200 Kg

Physico-chemical Properties of Cationic Bitumen Emulsion as per IS:8887- 2004 And Our Report.


Properties of Bitumen Emulsion

Requirement

Result.

Residue on 600 micron IS sieve(% mass)

0.05 max.

0.02

Viscosity by Saybolt Furol Viscometer, seconds At 500 C

50 - 300

64

Coagulation of emulsion at low temperature

Nil

Nil

Storage stability after 24 hrs. , %, max.

1.0

0.62

Particle charge

+ve

+ve

Coating ability and water resistance
(a) Coating, dry aggregates
(b) Coating after spraying water
(c) Coating, wet aggregates
(d) Coating after spraying water


Good
Fair
Fair
Fair

Good

Stability to mixing cement, %coagulation

Nil

Nil

Miscibility with water (coagulation)

No
Coagulation--

No
Coagulation--

Test on residue :
(a) Residue by evaporation, %
(b) Penetration, 250C/100 gm/5 sec.
(c) Ductility, 270C/cm.,
(d) Solubility In Trichloroethylene, %


65 min.
60-150
50 min.
98 min.


66
99
74
99


Bitumen Emulsion S.S.
Key Features:

  • Invert emulsion used for prime coat and fog spray

Advantages:

  • Coats and bonds loose mineral particles on the surface of the base course
  • Seals surface pores and makes the surface of the base course water-resistant
  • Penetrates the WMM surface so as to plug the capillary voids in it
  • Hardens and toughens the base course
  • Penetrates miniature pores of Sub-base
  • Compatible with ordinary portland cement

Technical Specifications:

  • Key properties as per IS 8887: 2004

Product Applications

  • Application rate as per Morth specifications

Emulsion S.S. is available in

  • Bulk
  • RC Drums 200 Kg
  • MS Drums 200 Kg

Physico-chemical Properties of Cationic Bitumen Emulsion as per IS:8887- 2004 And Our Report.


Properties of Bitumen Emulsion

Requirement

Result.

Residue on 600 micron IS sieve(% mass)

0.05 max.

0.04

Viscosity by Saybolt Furol Viscometer, seconds At 250 C

30 - 150

68

Coagulation of emulsion at low temperature

Nil

Nil

Storage stability after 24 hrs. , %, max.

2.0

1.28

Particle charge

+ve

+ve

Coating ability and water resistance
(a) Coating, dry aggregates
(b) Coating after spraying water
(c) Coating, wet aggregates
(d) Coating after spraying water

-

-

Stability to mixing cement, %coagulation

2

1.05

Miscibility with water (coagulation)

No
Coagulation--

No
Coagulation--

Test on residue :
(a) Residue by evaporation, %
(b) Penetration, 250C/100 gm/5 sec.
(c) Ductility, 270C/cm.,
(d) Solubility In Trichloroethylene, %


60 min.
60-120
50 min.
98 min.


62
108
72
99



Trade Information
  • Payment Terms
  • Cash in Advance (CID), Cash Advance (CA)
  • Delivery Time
  • 7 Days
  • Main Export Market(s)
  • Asia
  • Main Domestic Market
  • All India
